NMEA2000 M12 5 Pin Connector A Code Terminator Male To Female 120ohm Resistor

Name: NMEA2000 M12 5 Pin Connector A Code Terminator Male To Female 120ohm Resistor
Brand: CABLEFORCE
Price: 1 USD

China NMEA2000 M12 5 Pin Connector A Code Terminator Male To Female 120ohm Resistor wholesale

Brand Name : CABLEFORCE

Model Number : MC05TLAB

Certification : UL Certified, CUL Certified, CE/ EMC, IP67, IP69K

Place of Origin : Guangdong, China

MOQ : 100

Price : Negotiated

Payment Terms : T/T

Supply Ability : 60000 pcs/month

Delivery Time : 2~3 weeks

Packaging Details : Our standard packing: Individual part with transparent PE bag with label, OEM packing available.

Reference Standard : IEC 61076-2-101

Gender : Male to Female

Keywords : M12 Terminator Connector

Coding : A Coding

Insulation Resistance : ≥100MΩ

Contact Resistance : ≤5MΩ

Rated Current : 4A

Rated Voltage : 60V

Screw nut : Brass, CNC, Nickl-plated

Contacts Plating : AU (Gold)

Connector Body : TPU

Contact : Brass, Phosphor bronze

O Ring : FKM,NBR

Pollution Degree : 3

Protection Degree : IP67,IP68

Contact carrier : TPU+GF

Contact Now

NMEA2000 M12 5 Pin Connector A Code Terminator Connector Male to Female Molded 120 ohm Resistor

Connector Technical Data
Model Number	MC05TLAB
Contact No	5 pin
Insulation Resistance	≥100MΩ
Contact Resistance	≤5mΩ
Rated Current	4A
Rated Voltage	60V
O-ring	FKM/Silicon O-Ring
Rated Temperature	-25℃~+80℃
Locking System	M12 ×1.0 Screw
Tightening Torque	0.4Nm
Type	M12 Terminator Connector
Contace Body	TPU
Contact Carrier	TPU+GF
Screw Nut	Brass, CNC, Nickel-plated
Contact	Brass, Phosphor bronze
Contacts Plating	Au (Gold)
Pollution Degree	3
Protection Degree	IP67,IP68

Description

The M12 terminator is a M12 connector molded with a 120 ohm resistor inside, located at each end of the trunk line of DEVICENET, PROFIBUS DP, CANopen as well as NMEA 2000. Proper termination helps ensure signal integrity across the entire length of the cable.

● M12 A-Coded, B-Coded, D-Coded keyway connectors
● 120 ohm Resistor, +/- 1 ohm, 1/4W
● 4-Pole, 5-Pole available for both male or female connector

CABLEFORCE Products Features

● Sturdy metal coupling screws with anti-vibration design, 48 hours Salt Spray Test

● 360° shielded or non-shielded versions are available
● TPU over molded and PA+GF or metal shell

● UV Resistant, Hydrolysis Resistant,Oil resistant

● IP67 IP68 IP69K and UL approvals
● Temperature Range: Dynamic -25 ~ 80℃, Static: -40 ~ 80℃.
● RoHS, REACH compliant.

FAQ

● What is the Application of M12 Connector?

Senor and Actuator
Factory automation
Industrial safety control
Logistic and packaging
Railway transit
Industrial Ethernet
Vision Control

● How many times of Cable Moving Application Drag Chain can be chose?

5 Million times
10 Million times
20 Million times

●What's Cableforce Core Benefits can provide to customers?

Free Technical Consultation
Samples & Prototyping
Free Technical Drawings
Timeline Planning
Quality Control & 100% Testing 100%
Safe and reliable system that is easy to install
Manufactured, assembled and tested in our facility
Guaranteed for life
CE,IP67,UL Certified
Excellent weathering,UV and temperature resistance
High impact strength even
Ingress protection up to IP68
RoHS and REACH compliant
Free of halogen, LSZH
Excellent chemical resistance: to fuels, oils, alkalies, weak acids.
